Presentation
- Performance & productivity
- Safety & comfort
- Cost efficiency
Specifications
Performance & productivity
- Industry leading horizontal outreach of 23.85 m
- Smooth and precise movements
- Oustanding RT capacities
- Dual load 230 - 350 kg (optional)
Safety & comfort
- Haulotte Activ'Lighting System for safe loading / unloading in conditions of low visibility (optional)
- Ultimate control & comfort is engineered to provide superior working-envelope efficiency
- Rugged boom design
- Haulotte Activ’Shield Bar (optional)
Cost efficiency
- Haulotte Activ'Screen (on-board diagnostic)
- Haulotte Stop Emission System regulates engine run time, reducing fuel consumption, pollution and noise
- Easy access to all components
- Modular basket quick and easy to repair
| Working height | 27.9 m |
| Platform height | 25.9 m |
| Horizontal outreach | 23.85 m |
| Below ground reach | 3 m |
| Lift capacity | 230 kg (2 pers.) - option 350 kg |
| Platform size | 2.44 x 0.91 m |
| Length - stowed | 13.05 m |
| Storage / transport length | 9.8 m |
| Overall width | 2.48 m |
| Height - stowed | 2.85 m |
| Storage / transport height | 2.98 m |
| Vertical jib rotation | 133° (- 66° / + 67°) |
| Platform rotation | 180° (+ 90° / - 90°) |
| Turntable rotation | 360° continuous |
| Tailswing | 150 cm |
| Wheelbase | 2.8 m |
| Ground clearance | 48 cm |
| Tilt | 4 ° |
| Drive speed | 0.5 - 5 km/h |
| Maximum wind speed rating | 45 km/h |
| Gradeability | 45 % |
| Turning radius - outside | 6.55 m |
| Tyres - solid rough terrain | 1025 x 365 mm |
| Jib length | 1.83 m |
| Fuel tank | 120 l |
| Engine | Deutz 55.5 kW (Stage 5, LRC, China 4) |
| Weight | 17 900 kg |
- Haulotte Stop Emission System
- Haulotte Activ’Screen
- Universal telematics plug
- 4 wheel drive / 2 wheel steer
- Oscillating axle
- Haulotte smooth & proportional movements
- Automatic wheel differential lock
- Upper control box protection cover and tool tray in ultra-rugged composite
- Large modular basket 2.44 x 0.91 m
- Drop bar entry gate
- Basket rotation 180° (± 90)
- Swing out engine tray for easy maintenance access
- Sound and light alarm for tilt and load
- Motion alarm and rotating beacon light alarms
- Haulotte Activ'Lighting System
- Haulotte Activ'Shield Bar
- Non-marking tires
- Dual load capacity 230 - 350 kg (2 persons)
- 60 km/h wind speed
- Power to platform (female plug 230 V / 110 V)
- 1/2 in air line to platform
- Lateral swing door entry gate
- Hydraulic generator 3.5 kW or 6.5 kW
- Work light package
- Hydraulic oil cooler
- Cold weather package / arctic weather kit
- Glazier kit
- Pipe rack kit
- Motion flashing warning light
- Battery circuit breaker
