Presentation
- Best driving and lifting experience
- Utmost versatility
- Minimal maintenance and downtime
- Longer life time
Specifications
Best driving and lifting experience
- AC powered
- High precision driving
- Proportional and quick movements
- Best turning radius
Utmost versatility
- Ability to go through standard doorways
- Mobile potholes protection
- Indoor - outdoor rated
Minimal maintenance and downtime
- Maintenance free AC motors
- 2 easy access swing-out trays
- Haulotte Activ'Screen (onboard diagnostic)
- Smart transportability
Longer life time
- Haulotte Activ'Energy Management takes care of your batteries
- Extreme robustness
- Optimized total cost of ownership
| Working height | 7.77 m |
| Platform height | 5.77 m |
| Max. drive working height | 5.77 m |
| Lift capacity - inside | 230 kg (2 pers.) |
| Lift capacity - outside | 230 kg (1 pers.) |
| Lift capacity on the extension | 120 kg |
| Platform length | 1.72 m |
| Platform length - extended | 2.59 m |
| Length - extension | 0.86 m |
| Lenght - extension XL option | 0 m |
| Platform width - outside | 0.74 m |
| Platform size - extended | 2.59 x 0.74 m |
| Height - stowed | 1.98 m |
| Overall width | 0.79 m |
| Length | 1.9 m |
| Wheelbase | 1.38 m |
| Ground clearance - center | 8.7 cm |
| Ground clearance - deployed potholes | 2 cm |
| Drive speed | 0.5 - 4.5 km/h |
| Gradeability | 25 % |
| Tilt | 1.5° / 3° |
| Turning radius - outside | 1.5 m |
| Non-marking tyres | 12.5 x 4.13 |
| Batteries | 24 V - 225 Ah |
| Hydraulic system capacity | 7 l |
| Weight | 1 590 kg |
| Working height - indoor | 0 m |
| Working height - outdoor | 0 m |
| Platform height - indoor | 0 m |
| Max. drive working height - indoor | 0 m |
| Working height - indoor | 0 m |
| Working height - outdoor | 0 m |
| Platform height - indoor | 0 m |
| Max. drive working height - indoor | 0 m |
- Haulotte Activ'Energy Management: Smart CAN charger
- 24 V electric drive brushless AC motors
- Battery level indicator on upper and lower control boxes
- Haulotte Activ’Screen (battery charge, Hourmeter, service alert & failures icons in code or in full text...)
- Pothole guards
- 2 swing out trays
- Lateral fork lifting pockets
- 2 front steering and 2 rear driving wheels
- Proportional controls
- Electric or manual break release system
- Tilt sensor
- Lifting and stowage points
- Non marking tyres
- Folding guardrails
- AC power to platform
- Hydraulic oil for cold countries
- Telematics ready
- Flashing light
- Dual flashing lights
- Working light
- Panel carrier
- AGM maintenance-free batteries
