Presentation
- Optimal agility in confined working areas
- Minimal maintenance & downtime
- Longer life time
- Smart transportability
Specifications
Optimal agility in confined working areas
- Progressive electric drive AC motors
- Zero tail swing
- 3 m outreach vertical jib
Minimal maintenance & downtime
- Maintenance free brushless AC motors
- Haulotte Activ'Screen (onboard diagnostic)
- Haulotte Activ'Energy Management takes care of your batteries
- Almost 0 battery maintenance : automatic & centralized waterfilling system
Longer life time
- Unbreakable hoods in composite material
- Durability multiplied by 3 on pins, bushes, non-painted parts and fastening hardware
Smart transportability
- Versatile and effective transport solutions with forklift tine pockets
- 25 % gradeability to easily climb truck ramps
| Working height | 10 m |
| Platform height | 8 m |
| Horizontal outreach | 3 m |
| Lift capacity - inside | 200 kg (2 pers.) |
| Lift capacity - outside | 200 kg (1 pers.) |
| Platform size | 0.78 x 0,98 m |
| Length | 2.7 m |
| Width | 1 m |
| Height - stowed | 1.99 m |
| Tailswing | 0 cm |
| Wheelbase | 1.2 m |
| Ground clearance | 10 cm |
| Drive speed proportional | 0.6 - 5 km/h |
| Turning radius - outside | 1.88 m |
| Turntable rotation | 345 ° |
| Tilt alarm | 3 ° |
| Gradeability | 25 % |
| Max driveable platf. height | 8 m |
| Tyres - non marking | 16 x 5 x 10.5 |
| Power source | 24 V - 250 Ah |
| Weight | 2 677 kg |
| Vertical jib rotation | 130° (+ 70 ° / - 60 °) |
| Hydraulic system capacity | 7 l |
- Haulotte Activ'Energy Management: Smart CAN charger
- Automatic centralized battery filling
- 24 V electric drive brushless AC motors
- 24 V – 250 Ah traction batteries
- Battery charge indicator
- On-board diagnostic tool Haulotte Activ’Screen
- Forklift tine pockets
- Towing hooks and lifting eyes
- Passive potholes
- 2 front steering wheels
- 2 rear driving wheels
- Non-marking tires
- Brake release
- Hourmeter
- Horn
- Emergency stop buttons at cage and ground level
- Load controller in the platform
- Emergency hand pump
- 2 control stations at cage and ground level
- Drop bar entry
- 2 rings in the platform for safety harnesses
- Travel alarm
- Haulotte Activ’Shield Bar
- Power line in platform
- Air line in platform
- Swing door entry gate
- Biodegradable oil
- Maintenance-free batteries
- Telematics ready
- Hydraulic oil for cold countries
- Flashing light
- Working light
