Swift Up 4.5 SP
Swift Up 4.5 SP
Swift Up 4.5 SP

Low-Level Access Swift Up 4.5 SP

Low-Level Access platforms represent a simple, safe and efficient alternative to ladders and scaffolds.

Product characteristics

Indoor

Indoor

Even ground

Even ground

Electric

Electric

Application fields

Finishings

Finishings

Logistic / Retail / Industry

Logistic / Retail / Industry

Maintenance & Restoration

Maintenance & Restoration

Sporting & other events

Sporting & other events

Swift Up 4.5 SP

Presentation

  • Tiny machine, high productivity
  • Low size, high agility
  • Low maintenance, easy to use

Specifications

Tiny machine, high productivity

Tiny machine, high productivity

  • Ultra compact design: fit through single doors, elevators...
  • Narrow turning radius to fit with confined spaces constraint
  • Lightweight to work on sensitive grounds or in multi-story projects
Low size, high agility

Low size, high agility

  • Small platform to work in tiny spaces
  • Heavy tools and material transportable at once : platform capacity up to 240 kg
  • Self propelled driveable at full height for easy repositioning
  • Access ramps up to 25%
Low maintenance, easy to use

Low maintenance, easy to use

  • No set up time, the machine is ready to use
  • Maintenance free battery

Working height 4.5 m
Platform height 2.5 m
Lift capacity 240 kg ( 1 pers.)
Platform size 1.04 m x 0.57 m
Length 1.2 m
Width 0.7 m
Height - stowed 1.8 m
Wheel base 0.91 m
Ground clearance 5 cm
Gradeability 25 %
Tyres size (front / back) 150mm x 48mm / 230mm x 80mm
Turning radius - Inside 0 m
Turning radius - Outside 0.99 m
Weight 430 kg
Motion Self-Propelled - Electric
Tilt 1.5 °
Battery 2x12V DC - AGM
4,5
Swift Up 4.5 SP
Swift Up 4.5 SP

  • Electrically driven lifting
  • Electrically driven motion thanks to the 2 drive wheels
  • Maintenance free AGM battery
  • Battery charger > 12 Ah
  • Battery level indicator on upper control box
  • Overload indicator on upper control box
  • Emergency lowering descent
  • 2 front castor wheels
  • Automatic wheel lock
  • Non marking rear wheels
  • Mobile potholes protection
  • Swing door
  • Mobile upper control box
  • Charger plug with dedicated storage box
  • Motion flashing light
  • Horn
  • Motion alarm
  • Tilt indicator on lower control box
  • Hour meter
  • Forklift pockets
